CD7F Refrigerated Compressed Air Dryer & Filters


Price:
Sale price£770

Prices excluding VAT and Delivery (added at checkout)
Our website allows you to order all parts. This does not mean this item is in stock.
Please contact us if you need something urgently, otherwise please take note of the below:
Stocked parts are shipped on a next day delivery via tracked courier service.
Non-stocked parts are shipped from 5-10 working days.
Compressors and dryers are not shipped next day.
Please note due to current border and shipment delays some incoming deliveries from overseas are taking longer to arrive.
Please bear this in mind when ordering. Prices subject to change without notice.

Description

CD7F Refrigerated Compressed Air Dryer

Dryer package complete with filters

See technical sheet for full info.

Air Flow Rate 3°C m3 /min: 0.70
Air Flow Rate 3°C m3 /min: 0.77
Air Flow Rate 3°C m3 /min: 0.83

Absorbed Power kw: 0.14

Power supply: 230/1/50

Dew Point ISO Class: 4

Max Pressure bar g: 16

Air Connection BSP: ½"

Refrigerant: R513A

Dimensions WxDxH mm: 390 x 432 x 453

Weight kg: 26

Standard features
Control panel: Electronic system type
Separator type: Demister type
Condenser cooling: Air cooled
Compressor type: Hermetic type
Ventilator motor: Pusher fan
Installation location: Indoor
Heat exchanger: Aluminium brazed plate
Drain discharge: Timed solenoid valve
Expansion method: Capillary tube
Electric protection: IP 42

Please call if you require more information.

Larger dryers available, please contact for quote.
